Paper Trays

	Xerox laser paper 500 sheets per package 016-1368-00 A/Letter 016-1369-00 A4   Use Xerox paper for best results.
Tray sizes:	436-0282-02 A/Letter 436-0283-02 A4 436-0314-02 Legal
Paper weight:	60 - 90 g/m2 16 - 24 lb.
Tray capacity:	250 sheets (75 g/m2, 20 lb. paper)

Transparency Trays

	Xerox Transparencies 50 sheets per package 016-1654-00 A/Letter 016-1655-00 A4   Use only Xerox transparencies.
Tray sizes:	436-0284-02 A/Letter 436-0285-02 A4
Tray capacity:	100 sheets

Multi- Purpose Tray

	Use the Multi-Purpose Tray for specialty media.
Media sizes:	Metric: 88.9 x 254 mm -- 216 x 355.6 mm U.S: 3.5 x 10 in. -- 8.5 x 14 in.
Tray capacity:	up to 100 sheets, depending on media type and weight
Media types:
Xerox Laser Paper 500 sheets per package 75 - 150 g/m2 20 - 40 lb.	016-1368-00 A/Letter 016-1369-00 A4
Xerox Transparencies 100 sheets per package	016-1654-00 A/Letter 016-1655-00 A4
Xerox Glossy Coated Paper 100 sheets per package	016-1704-00 A/Letter 016-1705-00 A4
Xerox Fabric Transfer 100 sheets per package	016-1637-00 A/Letter
Laser Labels
#10 Envelopes
Cover stock up to 163 g/m2, 60 lb.
Card stock up to 163 g/m2, 40 lb.
Index up to 163 g/m2, 90 lb.

Margins and print area

The image area of a print is a bit smaller than the media size. You may need to adjust the page margins in your application software to match the print area.

To assure the correct page margins, use the drivers supplied on the printer's CD-ROM.

Media hints

Do not use any media designed for inkjet printers, especially inkjet coated paper and inkjet transparencies. Inkjet media is coated with a substance that will damage the fuser; Xerox does not furnish service for damage or malfunction caused by the use of non-Xerox supplies or consumables. Always use Xerox media that has been specially designed for use with Xerox Laser Printers.

• For the best print quality, load only paper in the paper tray and Xerox transparencies in the transparency tray.
• When printing a large number of sheets of paper or transparencies, use the media-specific trays for best reliability.
• If you have the Automatic Duplex/Lower Tray Assembly:
• Insert the Duplex Unit only in the upper ( a ) slot.
• Insert the transparency tray only into the middle ( b ) tray slot.
• Insert the Paper tray into the middle ( b ) or lower ( c ) slot.
• Always use the Multi-Purpose Tray ( d ) for specialty media.
• When using the Multi-Purpose Tray, always select the appropriate media type in the front panel after loading the media.
• When you select a media tray by location ( Upper, Middle, Lower, Multi-Purpose Tray ), the printer picks from that tray, regardless of the tray's media type or size.
• Always keep media in a sealed package to avoid the effects of moisture and dryness, which can affect print quality.

For details on automatic duplex printing, refer to Automatic duplex.
